Grooved End Pilot-Operated PRV: Unique Conduit-Free Design Enables Rapid On-Site Pressure Adjustment

Model BGR, a Grooved End Pilot Control Pressure Reducing Valve reduces pressure of inlet flow into desired outlet pressure. Pressure Reducing Valve can prevent damage within pipelines due to high pressure. Unique piston design to exclude conduit piping, made it compact size which is easy for transportation and assembling. Simple pilot control allows on-site pressure adjusting.

Key Features and Benefits of Grooved End Pilot Control Pressure Reducing Valve

• No Conduit, Compact size for easy Transportation, Installation, Maintenance and Repair.
• Maintain outlet pressure regardless fluctuate inlet pressure.
• Pressure reducing valve is suitable for general liquids and gases.
• Convenient in-style mounts either horizontally or vertically.
• Wide range capacity to handle local water supply pressure and adjust to specific pump specifications.
• Adjusting pilot allows easy calibrated pressure adjustment.
• Easy maintenance, maintenance kits are available upon request.

Why Choose Z-Tide Grooved End Pilot Control Pressure Reducing Valve?

• Reliable Performance: Consistently regulates outlet pressure and protects pipelines from damage.
• High Flexibility: Conduit-free design and multi-directional installation fit diverse environments.
• User-Friendly Maintenance: Simple pilot adjustment with maintenance kits available.
• Versatile Usage: Compatible with both liquids and gases to meet various industrial needs.

Frequently Asked Questions(FAQ) of Grooved End Pilot Control Pressure Reducing Valve

Q1: What types of piping systems are compatible with this valve?

Suitable for various hydraulic system pipelines, supporting both liquids and gases.

Q2: Can it be installed horizontally and vertically?

Yes, the valve can be installed in either orientation, adapting to different piping layouts.

Q3: Will the outlet pressure remain stable?

Yes, the valve maintains the set outlet pressure even when the inlet pressure fluctuates.

Q4: Is maintenance complicated?

No, maintenance is straightforward. We provide maintenance kits to simplify servicing.

Catalogue(Model BGR)Add to Inquiry
