Model RELT / RELF, a Low Pressure Type Pressure Reducing Valve (PRV), also known as Low pressure regulator, function as a pressure reducing valve but gives a lower pressure adjusting range. Manufactured in Stainless Steel 316, with precise pressure control, and easy to maintain and install.

What is the difference between the RET/REF models and the RELT/RELF models?

Both RET/REF and RELT/RELF models are direct acting pressure reducing valves. The RET/REF series is designed for standard pressures from 1 to 13 bar, while the RELT/RELF series is optimized for low pressures between 0.2 and 1.5 bar.

Applications of Low Pressure Type Pressure Reducing Valve

Key Features and Benefits of Low Pressure Type Direct Acting Pressure Reducing Valve

• Low Pressure Type Direct Acting Pressure Reducing Valve is suitable for general liquids and gases.
• Suitable for process automation control and many general purpose applications.
• Wide range capacity to handle local water supply pressure and adjust to specific pump specifications.
• Adjusting nut allows easy calibrated pressure adjustment.
• SS316 lower body and upper body construction for durability and compatibility.
• The balanced piston design provides a constant outlet pressure even when the inlet pressure is unstable. The supplied pressure gauge indicates the outlet pressure.
• Easy maintenance, maintenance kits are available upon request.

Project Reference: Direct Acting Low Pressure Type Pressure Reducing Valve for Turkish Chemical Pipeline

In a chemical process pipeline project in Turkey, our low pressure type direct acting pressure reducing valve demonstrated stable performance and excellent durability under demanding conditions of high temperature, high pressure, and continuous operation. The client adopted this valve for precise fluid pressure regulation, not only meeting their stringent safety and performance standards but also fully satisfying their requirement for high operational reliability. This effectively proved its high reliability and efficiency in industrial applications.

Frequently Asked Question(FAQ) about Low Pressure Type Direct Acting Pressure Reducing Valve

Q1: What does a low pressure regulator do?

A low pressure regulator maintains a stable low downstream pressure, even if the upstream pressure fluctuates. It protects pipelines and equipment by reducing high inlet pressure and ensuring safe and consistent operation of gas or liquid systems.

Q2: Where can a low pressure regulator be used?

Low pressure regulators are suitable for a wide range of liquid and gas systems, including industrial water supply, building plumbing, food & beverage processing, pharmaceutical systems, and other applications where stable downstream pressure is required.
